Swing over bed: 380 mm
distance between centers: 1000 mm
taper turning length max: 350 mm
swing over cross slide: 215 mm
Spindle bore: 40 mm
taper: 50 metric
cone bits: MORSE 3
front end of the spindle according to ISO: M 68
bed width: 340 mm
Chuck diameter: 165 mm
diameter face plate: 320 mm
Diameter of drive wheels: 220 mm
Spindle speed: 21 degrees in the range: 14-2800 rev / min
Feeds: Number 52
the long-range: 0.02 to 5.6 mm / rev
cross-range: .01 to 2.8 mm / rev
threads: metric, gradient: 0.2-140 mm
Whitwortovy conclusions: 5-140
module: module 0.25-70
Diametral pitch DP 1-224
electric motor to drive the machine: speed 2800 rev / min
Power: 6 kW
floor area of ​​the machine: width mm 950 mm
Length: 2720 mm
Machine weight: 1780 kg
Manufacturer: TOS Trencin

complete overhaul in the year: 2011
